Mux

Mux is a video technology platform that provides infrastructure and tools for developers to build and stream high-quality video content.

Grab Credentials

1. Sign in to mux.com.
2. Click on “Settings” at the bottom left, then select “Access Token”.
3. Select “Generate new token”.
4. Assign read permissions for Mux videos and data, and give the token a name.
5. Click on “Generate token”.
6. Copy the API access token and secret key for later configuration.

Connection Properties

The config section in a YAML file includes the following properties:

connector_name: Mux
Mux_api_access_token: Access token
mux_api_secret_key: API secret key

Example Configuration

version: 1
encrypt_credentials: false
plugins:
  extractors:
    - name: mux_data
      connectorname: Mux
      config:
        mux_api_access_token: <API TOKEN>
        mux_api_secret_key: <SECRET KEY>
      select:
       -views/assets

Configure the Data Hub to connect Mux

1. To start, Click the Bold Data Hub icon on the Navigation Pane.

2. Click Add Project and provide the name for the new project.

3. Select the newly created project and add the Mux template.

4. Update the Mux Api Access Token and Key in the template. Also, Update the resources on the select property and Click Save, choose the desired destination to save the pipeline.

5. Creating a Pipeline in Bold Data Hub automatically creates a Data Source in Bold BI. The Bold BI Data Source is a live data source to the destination database used in Bold Data Hub. For more information on the relationship between Bold Data Hub Pipeline and the associated Data Sources in Bold BI , please refer to Relationship between Bold Data Hub Pipeline and Associated Data Sources in Bold BI

The available resources are supported in Mux
- asset
- video
- view

Warning:

1. The `Encrypt_Credentials` property should be set to false when updating the new access token on the template. If you have modified other properties, such as 'select' or 'account id', the `Encrypt_Credentials` property must be set to true.
2. The default lifetime of the access token is 1 hour. Therefore, you need to convert it to a long-lived access token in order to use the same token for 60 days. Existing tables should be maintained even if the token has expired or is being used as an invalid token.

Schedule Data Hub Job

1. To configure interval-based scheduling, click on the schedules tab and select the created pipeline and click on the schedule icon and configure it.

2. For on-demand refresh, click Run Now button.

.

3. The Schedule history can be checked using the history option as well as logs.

4. Click on Logs to see if the run is completed and data source is created in Bold BI.

5. Click Edit DataSource Option to view the created tables.
